Simulate analog behavior of electric & electronic circuitry. Combine with digital system to run mixed-signal simulation
VisualSim library for Analog Behavioral Modeling provides an algorithmic view of how sub-systems interact, as well as verify system functionality in various applications before committing to a design. This will prevent problems that may be caused late in the design-cycle by incompatibilities between the individual blocks that comprise the overall system. VisualSim has a unique set of models of computation that enables analog and digital systems to be simulated in their native domain. This enables the designer to view the losses or impact of moving from digital to analog and back. At the same, VisualSim also provides models to study the performance of lossy channels, multi-channel, multi-gigabit ADC.
